KCB gear oil pump technical paramter:
Flow: 1.1m3/h-570m3/h
Discharge pressure: 0.28Mpa-1.45Mpa
Manufacturer:botou haina pump
Speed: 720rpm-1450rpm
Main types:KCB55 KCB200 KCB300 KCB960
Dia of inlet & outlet: 3/4″-14″
Applicable temperature: 0-200 degrees Celsius.
KCB gear oil pump is mainly used for all kinds of mechanical equipment of conveying lubricating oil in the lubricating system, can transport without lubrication oil, beverage, low corrosive liquid. KCB mainly include gear, gear pump shaft, pump body, valve, shaft end seal.
KCB gear oil pump is mainly used for all kinds of mechanical equipment of conveying lubricating oil in the lubricating system, can transport without lubrication oil, beverage, low corrosive liquid. With copper gear can handle liquid low flash point, such as gasoline, benzene, etc. This series of stainless steel pump in addition to the ordinary motor, can also according to customer’s need to be configured with the specifications of the explosion-proof motor.
KCB gear oil pump performance parameter:
| Model | Caliber (Inch) |
Flow (L/min ) |
Pressure (MPa ) |
Suction Lift (m ) |
kcb gear pump with Motor power (KW ) |
| KCB-18.3 | 3/4 | 18.3 | 1.45 | 5 | 1.5 |
| KCB-33.3 | 3/4 | 33.3 | 1.45 | 5 | 2.2 |
| KCB-55 | 1″ | 55 | 0.33 | 5 | 1.5 |
| KCB-83.3 | 1 1/2″ | 83.3 | 0.33 | 5 | 2.2 |
| KCB-135 | 2″ | 135 | 0.33 | 5 | 4 |
| KCB-200 | 2″ | 200 | 0.33 | 5 | 4 |
| KCB-300 | 3″ | 300 | 0.33 | 5 | 5.5 |
| KCB483.3 | 3″ | 483.3 | 0.33 | 5 | 7.5 |
| KCB483.3 | 3″ | 483.3 | 1.0 | 5 | 11 |
| KCB-633 | 4″ | 633 | 0.28 | 5 | 11 |
| KCB-960 | 4″ | 960 | 0.3 | 5 | 18.5 |
| KCB1200 | 6″ | 1200 | 0.6 | 3 | 37 |
| KCB1600 | 6″ | 1600 | 0.6 | 3 | 45 |
| KCB1800 | 8″ | 1800 | 0.6 | 2.5 | 55 |
| KCB2500 | 8″ | 2500 | 0.6 | 2.5 | 75 |
| KCB3800 | 10″ | 3800 | 0.6 | 2 | 110 |
| KCB5400 | 10″ | 5400 | 0.6 | 2 | 110 |
| KCB7600 | 14″ | 7600 | 0.6 | 2 | 200 |
| KCB9600 | 14″ | 9600 | 0.6 | 2 | 250 |
